HLEX LED
Explosion proof LED exit and emergency signage for hazardous locations
Industry
Industrial | Wastewater Treatment
Type
LED
Luminaire
Exit and Emergency | Explosion Proof | Hazardous Location | Industrial
Classification
The HLEX LED explosion-proof exit and emergency sign provides reliable, edge-lit signage for hazardous locations. It ensures safe egress with 3-hour emergency operation and versatile mounting options.
Standard Features:
- 3-hour emergency operation
- Field-replaceable LED circuit boards and drivers with quick disconnects
- Edge-lit sign
- Baked-on, epoxy-coated, die-cast, copper-free aluminum housing
Additional Features:
- Wall-, pendant- and end-mounting options
- Alternate exit legend and languages
- Single- or double-sided option
- Sealed NiCad batteries
- Three 1/2″ NPT hubs
- Red or green LED options
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Class II, Division 2, Groups F & G
- Class III
- UL 844 hazardous locations
- UL 1598A marine outside type
- UL 1598 wet locations
- IP65
- ETL listed
- NFPA 70 and NFPA 101 compliant
- Build America, Buy America Act (BABA) compliant
- Buy American Act (BAA) compliant
Standard Materials:
- Body: A356T6 aluminum (less than .4% copper content) with baked-on gray epoxy finish
- Gasket: one-piece silicone
- Sign: acrylic
- Hardware: stainless steel
Contact Us
Product Details
Approximate Shipping Weight: 14 lbs*
