FPF LED

NSF-certified LED linear lighting for high-pressure cleaning in wet, harsh-rated locations

Industry

Food Processing | General Purpose

Type

LED

Luminaire

Heavy Duty Harsh-Rated | Linear

Classification

BAA Compliant | BABA Compliant | DLC

The FPF LED linear light offers NSF-certified, debris-shedding lighting with a patented design ideal for harsh-rated and sanitary environments. Durable and easy to maintain, this heavy duty, non-metallic fixture is specifically engineered for high-pressure cleaning and wet locations.

Standard Features:

Patented liquid- and debris-shedding design
Patented dual gasket seals
3′ #16 AWG 3 conductor cable and cord grip
Single-bolt access to components
Field-replaceable LED circuit boards and drivers with quick disconnects
Industry leading watershed design
Impact resistant DR acrylic housing

Additional Features:

Diffused lens
Heavy-duty extruded aluminum LED tray
Optional emergency battery back-up with EM markings
Optional stainless steel end caps
Optional dimmable driver
Standard 10kV surge protection
Optional quick disconnect 3P plug and receptacle with 6’ cord
7-year warranty

Classifications:

UL 1598 wet locations
UL 8750 LED safety
CSA C22.2 No. 250.0-08
IP69K
NEMA 4X
NSF-certified food equipment
Tested to LM79, LM80 standards
DLC listed (on certain models)
Build America, Buy America Act (BABA) compliant
Buy American Act (BAA) compliant
-20°C to 35°C ambient temperature
85 CRI option available

Standard Materials:

Body/lens: DR acrylic
LED tray: 6063-T5 aluminum
Driver cover: 3105 H24 aluminum
End caps: polycarbonate
Gasket: silicone
Diffuser: acrylic
Hardware: stainless steel

Contact Us

Request More Information

To receive a quote or request additional information, please complete the form below and we will contact you as soon as possible. Fields marked with an asterisk (*) are required.

Product Details



View Dimensions



Lumens: 4,169-16,674


