EXA03 LED
EX-Series explosion-proof LED high-bay lighting for hazardous-rated locations
Industry
Industrial | Marine | Oil Field | Wastewater Treatment
Type
LED
Luminaire
EX-Series | Explosion Proof | Hazardous-Rated | High-Bay | Industrial Lighting
Classification
The EXA03 LED, part of the RIG-A-LITE EX-Series, delivers IECEx and ATEX-certified explosion-proof lighting for hazardous-rated environments. Built for the Middle East, North Africa, Southeast Asia, and other regions requiring ATEX/IECEx certification, it offers reliable high-bay illumination in demanding conditions.
Standard Features:
- Available in 30W, 40W, 50W, 60W, 70W
- Input voltage: AC100-277V, optional AC 277-480V
- Pendant, ceiling, wall, trunnion, 25° stanchion mounting options
- 120° beam angle
- Max operating temperature range: -40°C to 65°C
- IP66 & IK10 double protection
- Quick connection design, more convenient and faster installation and wiring
- Optional stainless steel guard
- Die-cast aluminum body and corrosion resistant frame
Classifications:
- Class I, Division 1, Groups B, C & D
- Class II, Division 1, Groups E, F & G
- Class II, Division 2, Groups F & G
- Class I, Zone 1, Groups IIB plus hydrogen
- Class I, Zone 2, Groups IIB plus hydrogen
- Zone 20 and Zone 21
- Zone 22
- IECEx approvals
• Ex db IIC T6/T5 Gb
• Ex tb IIIC T80 C/T95 C Db IP66 - ATEX approvals
• II 2G Ex db IIC T6/T5 Gb
• II 2D Ex tb IIIC T80 C/T95 C Db IP66 - UL 1598A marine outside type
- IP66
- IK10
