SAFR LED
Explosion proof LED wide-area lighting for harsh and hazardous locations
Industry
Industrial | Marine | Oil Field | Wastewater Treatment
Type
LED
Luminaire
Area | Explosion Proof | Hazardous Location | Industrial
Classification
The SAFR LED explosion-proof area light offers a low-profile, wide distribution design, delivering reliable illumination for hazardous and marine environments. With multiple mounting options and advanced features, it ensures safe, efficient lighting in extreme conditions.
Standard Features:
- Optics feature wide distribution pattern with uplight
- Hinged mount for access to internal components
- Field-replaceable LED circuit boards and drivers with quick disconnects
- Clear or diffused lens options
- Low profile
- No external fins
Additional Features:
- Supplemental 10kV surge protection
- Pendant, ceiling, wall, cone and stanchion mounting options
- Terminal block
- Optional prismatic refractors
- Optional adapter ring mates to select competitor mounts
- Optional stainless steel threaded inserts
- Optional stainless steel guard
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Class II, Division 1 & 2, Groups E, F & G
- Class III
- Zone 2, Groups IIA, IIB & IIC
- UL 844 hazardous locations
- UL 1598 wet locations
- UL 1598A marine outside type
- UL 8750 LED safety
- cUL
- IP66
- NEMA 4X
- ABS type approved
- Tested to LM79, LM80 standards
- DLC Listed LED
- Build America, Buy America Act (BABA) compliant
- Buy American Act (BAA) compliant
- 2.36 spacing criteria-compliant
- Up to 55ºC ambient temperature
Standard Materials:
- Body: A360 aluminum (less than .4% copper content) with baked-on gray epoxy finish
- Gaskets: one-piece silicone
- Lens: borosilicate glass
- Hardware: stainless steel
Note: The SAFR LED is rated for hazardous locations. For non-hazardous areas, see the ALI LED
Contact Us
Product Details
Lumens: 6,796-9,570
Approximate Shipping Weight: 15.5-18 lbs*
