EXA06 LED
EX-Series explosion-proof LED linear lighting for hazardous-rated locations
Industry
Industrial | Marine | Oil Field | Wastewater Treatment
Type
LED
Luminaire
EX-Series | Explosion Proof | Hazardous-Rated | Industrial Lighting | Linear
Classification
The EXA06 LED, part of the RIG-A-LITE EX-Series, delivers IECEx and ATEX-certified explosion-proof lighting for hazardous-rated environments. Built for the Middle East, North Africa, Southeast Asia, and other regions requiring ATEX/IECEx certification, it offers reliable linear lighting in demanding conditions.
Standard Features:
- Available in 20W, 30W, 40W, 50W, 60W, 70W, 80W, 100W
- Warm white/cool white color and colored R/G/B/Amber options
- Various installation methods are available to meet different application demands
- Type I, III, and V light distribution options
- End cable entry M25x1.5, M20x1.5, M32x1.5, 3/4″ NPT, 1/2″ NPT, and 1″ NPT
- Three conduit holes are reserved for interconnection of fixtures, greatly facilitating onsite installation and wiring
- Made of fiber-reinforced plastic, offering superior corrosion resistance for marine use
- Clear or diffused lens optional, 14 optic lenses for different light design requirements
- Provides up to 20W illumination for 90 minutes or 10W illumination for 3 hours of emergency lighting
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Class II, Division 2, Groups F & G
- Class III
- IECEx approvals
• Ex nR IIC T6/T5 Gc
• Ex tb IIIC T80 C/T95 C Db IP66 - ATEX approvals
• II 3G Ex nR IIC T6/T5 Gc
• II 2D Ex tb IIIC T80 C/T95 C Db IP66 - UL 1598A marine outside type
- IP66
- IK08
