AVPH LED
Explosion proof globe and guard hi-lumen LED area lighting for hazardous locations
$591.18
Industry
Industrial | Marine | Oil Field
Type
LED
Luminaire
Area | Explosion Proof | Globe and Guard | Hazardous Location | Industrial
Classification
The AVPH LED globe and guard area light provides explosion-proof, high-lumen lighting for hazardous locations. Its compact, rugged housing and glare-reducing frosted globe ensure reliable performance in wet and marine environments. Field-replaceable LED components with quick disconnects, multiple mounting options, and a protective guard enhance its versatility.
Standard Features:
- Compact luminaire with high lumen output
- Rugged 5/32″ thick housing
- Glare-reducing frosted globe
- Field-replaceable LED circuit boards and drivers with quick disconnects
- Standard protective guard
Additional Features:
- Ceiling, pendant and wall mounting options
- No external fins
- Optional dimming driver
- 2 kV surge protection
- 5-year warranty
Classifications:
- Class I, Division 2, Groups A, B, C & D
- Zone 2, Group IIA, IIB & IIC
- UL 844 hazardous locations
- UL1598 wet locations
- UL 1598A marine outside type
- UL 8750 LED safety
- cUL
- NEMA 3, 4 & 4X
- ABS type approved
- Build America, Buy America Act (BABA) compliant
- Buy American Act (BAA) compliant
- -20°C to +40°C ambient temperature
Standard Materials:
- Body: A360 aluminum (less than .4% copper content) with baked-on gray epoxy finish
- Guard: A360 aluminum (less than .4% copper content) with baked-on gray epoxy finish
- Gasket: one-piece silicone
- Lens: borosilicate glass
- Hardware: stainless steel
Note: The AVPH LED is rated for hazardous locations. For non-hazardous areas, see the AVP LED and BVP LED
QuickShip Model Information
| QuickShip Models | AVPH20L2UHFGC |
|---|---|
| Style | CIDII Compact Globe w/ Guard, Frosted Lens, Ceiling Mt |
| Watts | 20 |
| Operating Voltage | 120V – 277 V 50/60 Hz |
| Total Lumens | 1,769 |
| Lumens per Watt | 87 |
| CRI | 83 |
| CCT | 4,017 |
| Ambient Temperature | -20°C < Tamb <50°C |
Contact Us
Product Details
Lumens: 1,769
Approximate Shipping Weight: 4.1-5.4 lbs**
