EHW LED

Standard Features:

• Slim Profile and Lighter: Less than 100mm fixture height, perfect for mounting in confined or low-height areas
• Rugged Heat Sink: Superior thermal design provides cool operation from -40°C to +65°C (-40°F to +149°F)
• High Efficiency: Delivers up to 165lm/W and 4,950 lumens, reducing energy costs by up to 75% over conventional lamps
• Impact-Resistant PC Lens: UV polycarbonate lens passed IK09 test for extreme durability
• Quick and Easy Installation: Clamshell design easy access to drivers and multiple entries standard for easy through wiring

Additional Features:

• Universal voltage: AC120-277, 347-480V (50/60Hz)
• High efficacy up to 165lm/W
• CCT adjustable (3000K/4000K/5000K)
• Wildlife-friendly amber color options
• 10kV surge protector is standard, 20kV optional
• Dimming: Standard 1-10VDC
• Ambient operating temperature -40°C to 65°C
• Lumen maintenance L70 > 150,000 hours @ 25°C
• 5-year warranty

Classifications:

• Class I, Division 2, Groups A, B, C, & D
• Class II, Division 1, Groups E, F & G
• Class III
• Class I, Zone 2, Group IIC
• Zone 21, Zone 22
• UL 844 hazardous locations
• UL 1598 wet locations
• UL 1598A marine outside type
• UL 8750 LED safety
• CSA C22.2 No. 137-M1981
• CSA C22.2 No. 250.0
• IP67
• IK10
• NEMA 4X
• 5G
• Resistant up to 2,000 PSI hose-directed water
• Tested to 1000 hrs. salt spray to standard ASTM “B117-11”

Standard Materials:

• Body: Housing, splice box, and adapter are die-cast copper-free aluminum with baked powder epoxy/polyester finish
• Gaskets: High-temperature resistant silicone
• Lens: Heat, shock, and impact-resistant polycarbonate
• Hardware: Stainless steel with lacquer-free nameplate
